Connector Detail: SUMITOMO 6098-3811
Color: BK
Serviceability: Terminal Pigtail
| Cavity | Color | Size | Plate | Destination | Terminal | Seal | Service Part | Depinning Tool |
|---|
| 1 | RD/BU | 0.35 | SN | Z94-PAC06-R | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 2 | RD/GY | 0.35 | SN | X968F-8 | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 3 | OG | 0.35 | SN | X967F-7 | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 4 | GN | 0.35 | SN | X967F-8 | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 5 | BK/WH | 0.35 | SN | X967F-9 | SUMITOMO 8100-3625 | | 1099530-00-A | |
| Cavity | Color | Size | Plate | Destination | Terminal | Seal | Service Part | Depinning Tool |
|---|
| 1 | RD/BU | 0.35 | SN | Z94-PAC06-R | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 2 | RD/GY | 0.35 | SN | X968F-8 | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 3 | OG | 0.35 | SN | X967F-7 | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 4 | GN | 0.35 | SN | X967F-8 | SUMITOMO 8100-3625 | | 1099530-00-A | |
| 5 | BK/WH | 0.35 | SN | X967F-9 | SUMITOMO 8100-3625 | | 1099530-00-A | |
