Connector Detail: SUMITOMO 6098-5650
Color: WH
Serviceability: Terminal Pigtail
| Cavity | Color | Size | Plate | Destination | Terminal | Seal | Service Part | Depinning Tool |
|---|
| 1 | RD/WH | 1.5 | SN | X945M-10 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 2 | GY | 1.5 | SN | X945M-18 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 3 | BK | 1.5 | SN | G660-1 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 4 | BK | 1.5 | SN | G660-1 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 7 | BU/WH | 1.5 | SN | X943M-10 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 12 | GN/WH | 1.5 | SN | X944M-10 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 13 | BU | 1.5 | SN | X943M-18 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 18 | GN | 1.5 | SN | X944M-18 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| Cavity | Color | Size | Plate | Destination | Terminal | Seal | Service Part | Depinning Tool |
|---|
| 1 | RD/WH | 1.5 | SN | X945M-10 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 2 | GY | 1.5 | SN | X945M-18 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 3 | BK | 1.5 | SN | G660-1 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 4 | BK | 1.5 | SN | G660-1 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 7 | BU/WH | 1.5 | SN | X943M-10 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 12 | GN/WH | 1.5 | SN | X944M-10 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 13 | BU | 1.5 | SN | X943M-18 | SUMITOMO 8230-4923 | | 1099534-00-A | |
| 18 | GN | 1.5 | SN | X944M-18 | SUMITOMO 8230-4923 | | 1099534-00-A | |
